STEREO EQUALIZERS, REVERBS / SIGNAL PROCESSORS VINTAGE AND USED


Used & Vintage Stereo Signal Processors. EQ's, Spring Reverbs, Dynamic Processors, Delays, Quadraphonic Decoders, DBX units, Tape-Monitor / Signal-Input-Source Selectors, Digital Timers / Rack-mount clocks, Etc. Fully Tested by Qualified personnel with over 58 years combined experience! Ready to GO! Refurbished, Rebuilt where necessary and Warranted.  Brands such as ADC, AUDIO-SOURCE, Bose, DBX, EMPIRE, MARANTZ, PIONEER RG / SG / SR, SAE, SANSUI RA / SE / SR, Sony, TEAC, Yamaha, and many others...














AUDIO EQUALIZERS
and our philosophy on them.

                               "Are Equalizers really necessary? I just paid $30 grand for my speakers. They shouldn't need any EQ. Right!??"

Short answer is probably yes, an EQ will generally be beneficial to most systems.
     Most speaker designers strive to make a speaker's curve as "flat"* as their projected size parameters and target retail price will allow. The human hearing curve is not "flat". Most folks' hearing is accentuated in the midrange (it's where the human voice is centered) and attenuated in the bass and treble. Sort of a reverse "rock-n-roll smile" curve. When you hear a good, "flat" response speaker, it will likely appear to have an over abundance of mids, at least for most listeners. It will also likely have a deficiency in bass and possibly treble. It will most likely sound  "thin", the degree of which can vary from slight to extreme, depending again, on many variables. This might not even be readily apparent when auditioning speakers, but generally if you hear a pair speakers with an appropriately adjusted, EQ engaged, then you listen to it bypassed, you will want to re-engage it as quickly as possible.
     The classic arguments against using an EQ have been that an EQ, or any additional inserted signal processing device, makes the signal path less "pure" and adds noise. Also, again, "these speakers were expensive and shouldn't need an EQ". To address the first point, this issue can usually be reduced to a more than desirable point by utilizing a high quality EQ or signal processor. The noise floor should certainly be below audible levels, and it doesn't take too much of an EQ to achieve that for most folks systems.  While the first point is valid, a good EQ's benefits usually far outweigh any minor noise issues, which are probably below most listeners audible limits in the first place. The second issue was answered previously, in the above paragraph.   In fact, the better the speakers, the more they would likely benefit from a reduction of the midrange frequencies, due to their as "flat as possible" curve. Again, this would apply to the average persons hearing curve. Some "cheap" speakers, will have a "rock-n-roll smile" EQ curve built-in by utilizing drivers, crossover and cabinet combinations, that have an over abundance of bass and treble, and a deficit of mids by design. That would beg the question of "why wouldn't they all just do that then". The answer to that is that any respectable speaker manufacturer wouldn't try and dictate a built-in curve into a speaker other than as flat as assigned parameters will allow, for a number of reasons.
     Another less apparent, but still valid reason for utilizing an EQ can be to compensate for listening room acoustic characteristics. This is generally more difficult to assess, but overtime could become a desired need. This need would obviously change with any parameter change in the listening environment. Also, and no offense, but as we age and as we are exposed to various, sometimes, injurious sonic environments and events, our sensitivity to frequency ranges will change.
     One way to look at a specific speaker / listening environment combination is to think of it as a blank artists canvas. A really high quality speaker system would be comparable to a high quality canvas, brushes and material. Said another way, a "non-flat" EQ curve / listening environment / speaker combination is akin to starting your painting with a dirty, blotchy canvas. The listening environment to a well lit room with natural lighting, conducive to a creative mood. Until you "shape" the EQ, there is no painting on the blank canvas. Once you shape the EQ to your tastes, in a way that compliments the speaker design / room combination, you have created your work of art.

    While I can appreciate all the arguments for not using an EQ, in the end, I generally use an EQ with it's curve slightly boosted in the bass and treble frequencies and attenuated through the mid frequencies from "Zero" position (the "rock-n-roll smile" curve). It will usually require adjustment following any change in speakers, listening environment parameter adjustments and with the material I am listening too. I also have a 1/3 octave RTA monitor / spectrum analyzer with a pink noise generator and analyzing mic to establish an accurate "flat" point to start from.

 * Contrary to a somewhat common misconception, "Flat" does not mean "dull". "Flat" refers to the graphic "curve" of a speakers output when analyzed by a spectrum analyzer. Ideally a speaker should be able to reproduce the human hearing range with all frequencies as close to "zero" (even amplitude or "flat") as is practical for the intended design / price point levels. The listener can then modify it from there by various methods (usually some sort of signal processor such as an EQ) to their tastes.












NEW LISTING
5/17/16
(Click on above thumbnails to enlarge photos)

VINTAGE PIONEER SG-90
PIONEER GRAPHIC EQUALIZER EQ
#...647S
STEREO 12 BAND "OCTAVE" EQ

Circa 1984-85
MIJ

for sale


ü  Our technician has completely gone through and 'Certified' this unit.

ü
  Everything was completely tested and benched.

ü  Most I/O jack and fader solder joints re-flowed for trouble-free service.

ü  Tape monitor and Attenuator switch locks checked for proper function. All 'latched' switches locking fine.

ü  All original LED's functioning.

ü  We then tested both channels with a test tone and O-scope, analyzing both channels with and without each independent effect.

ü  It was then cosmetically detailed inside and out.

ü  All functions tested for perfect operation.

ü  All inputs tested and both side produces clean and even sine waves!

ü  Checked with oscilloscope. No power supply hum of any kind. Floor noise measured >-60dB It's dead silent!


ü  Only minor cosmetic issue is a bit of scuffing (white marks) along a few of the bands in the center of the left channel. Nothing particularly distracting (see photos above). Overall, still looks fabulous and sounds great!

______________________________

The Pioneer, SG-90 Dual 12-band stereo, graphic EQ. Super quality dual 17 band stereo equalizer. Bands are less than 1/2 octave wide for VERY accurate cutting and / or boosting of frequencies. Frequency centers are at 16, 25, 40, 63, 100, 160, 250, 400, 630, 1k, 1.6k, 2.5k, 4k, 6.3k, 10k, 16k, and 25khz. Faders are all a full 60mm in length, are center de-tented and offer selectable +- 12 / 6db cut / boost. Okay, so here's the deal...this EQ is NOT for someone purchasing their 'first EQ', or someone who does not have a comfortable knowledge of 'signal flow' and 'signal routing'. It is fairly complicated to operate, and easy to get into a 'no sound' situation. Just a friendly warning. If you are familiar with EQ, and / or are willing to tackle a challenging learning curve with this on, then you should be fine.

Pioneer SG-90 features include:


- '~ 'One Half Octave' Stereo, 17-band Graphic EQ
- 17 'linear-fader' controlled frequencies per channel
- +- 12dB or 6dB Cut / Boost (most EQ's only allow 10dB)
- The 17 frequency centers are as follows (starting at the low-end): 16Hz - 25Hz - 40Hz - 63Hz - 100Hz - 160Hz - 250Hz - 400kHz - 630Hz - 1kHz - 1.6kHz - 2.5kHz - 4kHz - 6.3kHz - 10kHz - 16kHz & 25kHz.
- Long / 60mm Linear faders utilizing high quality potentiometers with a 'center detent'
- Dual Tape monitors (Tape Monitors can be used with Tape / Video / CD / DVD / VCR / DAT / MP3 / iPod® / iPhone® / iTouch® / iGadget / MP3 / XM® / SIRUS® CDR (CD recorders as well as for inserting signal processors, such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc) Dubbing can be used with CDR (CD recorders) units)
- Variable and and independent Source and Tape Input level controls
- EQ Record function, for imprinting EQ curve to recordings
- Curve 'Reverse' selector (useful for troubleshooting speakers / system)
- EQ defeat / bypass
- 'Auto Fader' fades between tape monitors and / or source
- Selectable 'Line Out' (we've never seen an EQ with this that we can remember)
- AC un-switched convenience jack located on the back, rated at a total of 100 Watts

Pioneer SG-90 Original Specs:

# Channels: 2 (stereo)
# Bands: 34 (1 stereo)
# Cut / Boost dB's: Selectable 12± or 6dB
THD: 0.001% @ 1V output & 1kHz
Gain: 0dB w/ all controls 'centered'
Output (RMS V): 6V @ 1K w/ 0.01% THD
Overall Frequency Response: 10-100kHz
Input Sensitivity / Impedance: 150mV / 47kΩ
Output / Impedance: 150mV / 200Ω
Tape Output Level / Impedance: 150mV / 2.2kΩ
S/N A-weighted (IHFA): 120dB @ 2V output w EQ flat


Overall, this is a great looking and performing EQ and is built using quality, center de-tented linear controls with +/- 12dB of range and a full 60mm of throw! Other than the previously mentioned light scuffing to the left channel fader slots, the unit looks great. Again, we have completely gone through cleaning it, refurbishing & checking all functions. All controls and switches cleaned for worry-free service.
Includes a pdf, 'e' copy, download of the Pioneer SG-90 Owners / Users / Instruction manual. Measures 16.5" wide x 14" deep x 5.25" high and weighs heavy at 16 lbs unpacked. Includes our standard 90 day limited warranty.
PIONEER SG-90 STEREO GRAPHIC EQ
Cond. 8.5
$459.


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)






NEW ADDITION 9/26/19
  (Click on above thumbnails to enlarge photos)
VINTAGE GRAPHIC EQUALIZER EQ
PIONEER SG-750 EQ
(same as Pioneer SG-50 w/ color differences)
#...1616S
STEREO 10 BAND "OCTAVE" EQ
W/ PINK NOISE AND
SPECTRUM ANALYZER

 Circa 1984-85

 MIJ
for sale


This is the 'North American' version of the Pioneer SG-50 EQ. Unit was completely bench checked inside and out. We tested both channels test tones and O-scope, analyzing both channels with and without each independent effect. It was then cleaned inside and out, then polished to near new look.
  Unit is clean both cosmetically and sonically. Looks and sounds great!
______________________________

 The Pioneer, SG-750 10-band "combined" stereo, graphic EQ w/ Pink Noise Generator and Spectrum Analyzer. Combining the faders into stereo units, as opposed to separate left and right is so much easier to utilize for most users.
 Other features include:


  - 'One Octave' Stereo, 10-band Graphic EQ
  - 10 'linear-fader' controlled frequencies per channel (combined stereo faders)
 - Pink Noise generator w/ Mic input for correctly analyzing a room
 - 10 Band, Fluorescent 'Bar Graph' Spectrum Analyzer
 - Analyzer 'Level' control
   - Full +- 10dB Cut / Boost
  - The 10 frequency centers are as follows (starting at the low-end):
  32Hz - 64Hz - 125Hz - 250Hz - 500kHz - 1kHz - 2kHz - 4kHz - 8Hz & 16kHz.
   - 60mm Linear faders utilizing high quality potentiometers with a 'center detent'
  - Tape monitor  (Tape Monitors can be used with Tape / Video / CD / DVD / VCR / DAT / MP3 / iPod® / iPhone® / iTouch® / iGadget / MP3 / XM® / SIRUS® CDR (CD recorders as well as for inserting signal processors, such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc) Dubbing can be used with CDR (CD recorders) units)
   - EQ defeat / bypass
 - Front mounted, 1/4" microphone input jack (for PN mic, not included, but any decent, Hi-Z mic with a 'Flat' response from 30-18k will suffice)
 - AC un-switched convenience jack located on the back, rated at a total of 100 Watts

 Original Specs:

  # Channels: 2 (stereo)
  # Bands: 10 combined stereo
  # Cut / Boost dB's: 10±
  THD: 0.003% @ 2V output & 1kHz
  Gain: 0dB w/ all controls 'centered'
  Output (RMS V): 6V @ 1K w/ 0.01% THD
  Overall band width: 50-100kHz
  Input Sensitivity / Impedance: 150mV / 50kΩ
  Output Sensitivity / Impedance: 150mV / 1kΩ
  S/N A-weighted: 116dB @ 2V output
  Display Resolution: 8 Steps @ 3dB / step


 An EQ with a Spectrum Analyzer built-in that actually does something besides just look cool! The built-in, Pink Noise generator with jack for optional mic allows actual room / system analysis for perfect EQ adjustment of the audio playback levels at the available frequencies. This is a great looking and performing EQ and is built using quality, center de-tented linear controls with a full 60mm of throw! Again, we have completely gone through cleaning it, refurbishing & checking all functions. All controls and switches cleaned for worry-free service. Again, the no PN mic is included, but any decent, Hi-Z mic with a 'Flat' response from 30-18k will suffice. Includes copy of owners manual. Measures 16.5" wide x 10.5" deep x 4" high and weighs 10 lbs unpacked. Includes our standard 90 day limited warranty.
 PIONEER SG-750
 Cond. 8.5++

$299.


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)






7/11/16 COMING SOON
(or at least as time allows):

ADC One-Ten MK II
Audio Source EQA-100
Empire GX-100
Marantz EQ-20
Pioneer SG-750
Pioneer SG-9500
Pioneer SG-9800

SAE 5000A
Sansui RA-700
Sony PT-59
Teac TT-2
and more...









NEW LISTING 6/22/16

(Click on above thumbnails to enlarge photos)

VINTAGE PIONEER GRAPHIC EQUALIZER
FISHER EQ-275
#...8324
Circa
mid 1980's
"WORLD AC POWER" ™
MIJ
for sale

ü  Our technician has completely gone through and 'Certified' this unit.

ü
  Everything was completely tested and benched.

ü  Most I/O jack and fader solder joints re-flowed for trouble-free service.

ü  Tape monitor and 'EQ' switches cleaned

ü  We then tested both channels with a test tone and O-scope, analyzing both channels with and without each independent effect.

ü  It was then cosmetically detailed inside and out.

ü  All functions tested for perfect operation.

ü  All inputs tested and both side produces clean and even sine waves!

ü  Checked with oscilloscope. No power supply hum of any kind. <00.1mvAC! It's dead silent!


ü  Cosmetically in 'Near New' condition

This Fisher EQ-275, Graphic Equalizer will add great sonic control to most stereo systems. Super quality build inside and out.

Fisher EQ-275 Features include:

- One Octave Graphic EQ
- 10 Graphic bands of control
- +- 12dB Cut / Boost (most EQ's only do 10dB)
- 55mm Throw, Linear Pots
- The 12 frequency centers are as follows (starting at the low-end): 16Hz-31.5Hz-63Hz-125Hz-250Hz-500Hz-1KHz-2KHz-4KHz-8KHz-16KHz & 32kHz
- Tape Monitor
 (Tape Monitors can be used with Video / CD / DVD / VCR / DAT / iPod / MP3 / XM / SIRUS CDR (CD recorders as well as for inserting signal processors, such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc) Dubbing can be used with CDR (CD recorders) units)
- EQ Record function, for imprinting EQ curve to recordings
- EQ defeat / bypass
 - Rear mounted, Un-switched AC convenient outlet rated at 100 watts

- "WORLD AC POWER"™ 50 / 60 cycles there is a 110V, 120V, 220V & 240V selector for use anywhere in the world!


This unit came from a retired Air Force Colonel, who purchased it in Okinawa, Japan, and supposedly never used any of it. That's how it looks too!  Again, as stated above, the unit has been completely evaluated, tested and cleaned inside & out.  Works and sounds GREAT! Looks essentially NEW! Comes with the original box / packing. Measures 17.25" wide x 12" deep x 4.25" high and weighs 10 lbs unpacked. Includes our standard 90 day limited warranty.
FISHER EQ-275 GRAPHIC EQUALIZER
Cond. 9.5
$289.


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)









NEW LISTING 5/3/16
(Click on above thumbnails to enlarge photos)
VINTAGE ADC / BSR SS-110-IC / 'ONE TEN'
ADC "SOUND SHAPER" STEREO GRAPHIC
OCTAVE EQUALIZER

Circa 1981

for sale
    We have just completely gone through this one. As the "EQ", Tape Monitor, and Record switches do not respond to the normal, simple cleaning on these ADC's, all three control "push" switches removed, disassembled, contacts individually burnished and completely cleaned with solvent for trouble-free service. This is a time consuming process, but the best way to insure performance. We injected both channels with 1kHz sine waves, and monitored switch performance on an oscilloscope with no visible issues after switch re-build. All fader LED's function. Great quality, dual 10 band EQ. Built very well and made for great "sonic" performance. These were one of the most sold EQ's ever made for a reason. Great sound, great looks and simple to use.

ADC SS-110-IC features:



 - Dual 10 band, 'Octave' Graphic EQ
 - Each of the graphic controls feature a full +-12db of cut / boost (instead of the common 10 db)
   - Long, 60mm in throw length, high quality, linear, de-tented faders (most home units are 30 - 40mm)
 - 10 frequency centers are as follows starting at the low-end: 31Hz - 62Hz - 125Hz - 250Hz - 500kHz - 1kHz - 2kHz - 4kHz - 8kHz & 16kHz.
 - Dual Tape Monitors (Tape Monitors can also be used for Tape / Video / CD / DVD / VCR / DAT / iPod /MP3 / XM / SIRUS etc. as well as for CDR)
 - EQ Recording function to imprint tapes / CD's / DAT's / Hard Drive with EQ curve for playback on a car stereo or to allow for deficiencies in speakers.
   - A-B Tape dubbing
   - EQ bypass
   - An un-switched AC convenience jack located on the back rated at 200 Watts

ADC SS-110-IC Original Specs:

  # Channels: 2 (stereo)
  # Bands: 10 (combined L&R)
  # Cut / Boost dB's: 12±
  Max Output (RMS V): 10
  THD: 0.01% @ rated output, 20-20kHz
  S/N A-weighted: 110 dB


  EQ is in great shape and looks NEW. Again, we have completely gone through this unit and tested all functions. It works and sounds GREAT! Measures 15.25" wide x 8.25" deep x 6.25" tall and weighs 10 lbs unpacked. Includes our 90 day limited warranty.
   ADC / BSR SOUND SHAPER ONE TEN-IC
   Cond. 9

 $239.


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)














AUDIO REVERBS / DELAYS




NEW LISTING 7/11/16
(Click on above thumbnails to enlarge photos)
VINTAGE
PIONEER SPRING REVERB
PIONEER SR-202W ANALOG SPRING REVERB
#...1149

"WORLD AC POWER" ™
 Circa 1973-75

MIJ

for sale
Our technician has completely gone through and 'Certified' this unit.
Unit was disassembled for restoration / reconditioning. All switches / controls cleaned. Springs, send and receive units inspected and re-soldered where necessary. Spring suspension inspected. All display and power lamp sockets 're-sprung' and their lamps / bulbs replaced with new. All RCA I/O jacks had their solder joints re-flowed. Display 'slide' mechanism cleaned and re-lubed. Control shafts check for 'true' and straightened where necessary. AC power voltage and fuse checked for correct setting and proper value. We then tested both channels with a test tone and O-scope, analyzing both channels with and without each independent effect. It was then cleaned inside and out, then polished to look great. Floor noise measured to -60dB! Only issue cosmetically is a minor scuff on the top edge and a minor cigarette burn to the top vinyl (neither particularly distracting).
 Unit performs and sounds great!

From the original brochure, "
The reverberation amplifier is one of Pioneer's unique products.  Unlike ordinary high fidelity systems that use single scatter systems, the SR-202 employs a double scatter system involving the merging and blending of two channels in a complex composite sound.  The direct signals from the pick-up that have been fed through the preamplifier, and the reverberation signals, which are comprised of the signals of the opposite channels to which reverberation effects have been added, are merged and blended to result in a composite sound that includes echoes and reflected sounds.  Two time delay circuits eliminate any peaks or dips in reverberation so what you hear is absolutely stable and has tremendous depth and brilliance.  The SR-202 reverberation amplifier can be used to increase the naturalness of your own recorded voice, radio broadcasts, records or tapes.  It can be coupled with your own system's amplifier (with tape monitor jacks) in various ways, to provide reverberation effects to the speakers only, or to just the recorded sounds, or both together.  You can even control two tape recorders at the same time by switch operation for simultaneous recording, recording with reverberation, playback etc.  In fact you can connect the SR-202 in practically any way you like for the effects you want. The system can be converted back to normal operation any time with the flip of just one switch."
 ______________________________

Pioneer SR-202W
Features;

- Dual spring, Analog Reverb tank
- Prismatic, Multi-Color reverb level display
- Mechanical Depth / Reverb Time control
- Record out with Effect selector
- Dual Tape monitors
- "Bi-Directional" tape dubbing
- Dual un-switched AC convenience jack located on the back rated at 300 Watts
- Externally located main protection fuse
- Ground lug
-  "WORLD AC POWER"™
  50 / 60 cycles there is a 110V, 120V, 220V & 240V selector for use anywhere in the world!

Pioneer SR-202 Original Specs:
Rated Output Voltage: 330mV @ 1kHz w/ Reverberation time minimum input level 200mV
Maximum Input Voltage: 3V @ 1kHz w/ Reverberation time @ minimum
Harmonic Distortion: Less than 0.2% @ 1kHz w/ Reverberation time @ minimum output level 330mV
Frequency Response: 20 to 35,000Hz  +/-2dB w/ Reverberation time @ minimum & 20 to 50kHz  +/-10dB w/ Reverberation time @ max
Signal to Noise Ratio: 65dB @ output level 330mV
Reverberation Time: 1.9 to 3.2 second @ 1kHz
Input Impedance: 300kΩ @ 1kHz
Output
Impedance: 10kΩ @ 1kHz


 Classic mid '70's "REAL" Analog, Spring Reverb. This one is in impeccably clean shape. Again, it's been completely gone through as stated earlier. Wood grain, vinyl wrapped cabinet in great shape. Face perfect as is display window. RCA inputs and outputs for 2 tape decks.  Also features dual AC convenience outlets. All original knobs in great shape! This thing looks near NEW. Has very strong send and receive coils on the reverb tank, so you can get HUGE reverb with this one if you wish. Also great for use in your studio. All original knobs in great shape! This thing looks new. Silk-screened chart on bottom shows a variety of hook-ups. True "WORLD AC POWER"™ 50 / 60 cycles there is a 110V, 120V, 220V & 240V selector for use anywhere in the world! Comes with an 'e' copy / pdf download of the Pioneer SR-202W owners / users / operations manual. Unit measures only 12.5" wide x 9.5" deep x 5.5" tall and weighs 10 lbs unpacked. Comes with our 90 day limited warranty.
PIONEER SR-202W
Cond. 9
 $249.

(Above text property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)








NEW LISTING 7/12/16
(Click on above thumbnails to enlarge photos)
VINTAGE
SANSUI RA-700 SPRING REVERB
STEREO ANALOG, REVERBERATION AMPLIFIER / SPRING REVERB UNIT

  "
WORLD AC POWER"

Circa 1978-82
MIJ
for sale
Our technician has completely gone through and 'Certified' this unit.
Unit was disassembled for restoration / reconditioning. All switches / controls cleaned. Springs, send and receive units inspected and re-soldered where necessary.
Both reverb spring junctions inspected and all send / receive coils in perfect, working order.  All display and power lamp sockets 're-sprung' and their lamps / bulbs replaced with new. All RCA I/O jacks had their solder joints re-flowed. Display 'slide' mechanism cleaned and re-lubed. Control shafts check for 'true' and straightened where necessary. AC power voltage and fuse checked for correct setting and proper value. We then tested both channels with a test tone and O-scope, analyzing both channels with and without each independent effect. It was then cleaned inside and out, then polished to look great. Floor noise measured to -60dB! Only issue cosmetically is a minor scuff on the top edge and a minor cigarette burn to the top vinyl (neither particularly distracting).
 Unit performs and sounds great!

_____________________________________


Sansui RA-700 Features;

- Dual spring, Analog Reverb tank
- Prismatic, Multi-Color reverb level display
- Mechanical Depth / Reverb Time control
- Record out with Effect selector
- Dual Tape monitors
- "Bi-Directional" tape dubbing
- Dual un-switched AC convenience jack located on the back rated at 300 Watts
- Externally located main protection fuse
- Ground lug
-  "WORLD AC POWER"™
  50 / 60 cycles there is a 110V, 120V, 220V & 240V selector for use anywhere in the world!

Sansui RA-700 Original Specs:
Rated Output Voltage: 300mV @ 1kHz w/ Reverberation time minimum input level 200mV
Maximum Input Voltage: 3V @ 1kHz w/ Reverberation time @ minimum
Harmonic Distortion: Less than 0.2% @ 1kHz w/ Reverberation time @ minimum output level 300mV
Frequency Response: 20 to 30,000Hz  +/-2dB w/ Reverberation time @ minimum & 20 to 30kHz  +/-10dB w/ Reverberation time @ max
Signal to Noise Ratio: 65dB @ output level 300mV
Reverberation Time: 1.9 to 3.2 second @ 1kHz
Input Impedance: >200kΩ @ 1kHz

Classic mid '70's Sansui, stereo "REAL" Analog, Dual Spring Reverb. This one is in impeccably clean shape. Again, it's been completely gone through as stated earlier. Wood grain, vinyl wrapped cabinet in great shape. Face perfect as is display window. RCA inputs and outputs for 2 tape decks. These things sound great. Add depth to your sound. Makes a room come alive. This one is in great shape. Great sounding internal, Real Analog Spring Reverb tank. Dual tape monitors with bi-directional dubbing. Record feature allows you to listen to the sound with reverb while not affecting or effecting your recording. Great looking multi-color display. Variable reverberation time. True "WORLD AC POWER"™  50 / 60 cycles there is a 110V, 120V, 220V & 240V selector for use anywhere in the world! Unit looks great. Comes with an 'e' copy / pdf download of the Sansui RA-500 (previous version of RA-700, and operation / function is identical) owners / users / operations manual. Condition is near NEW!! Unit measures 12" wide x 11" deep x 6.5" tall and weighs 12 lbs unpacked. Includes our standard 90 day limited warranty.
SANSUI RA-700 REVERBERATION AMPLIFIER
Cond. 9
$249.
(C) R.R.

(Above text property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)








AUDIO TIMERS





NEW ADDITION 2/4/11
 (Click on above thumbnails to enlarge photos)
VINTAGE PIONEER AUDIO TIMER / DIGITAL CLOCK
DT-570 DT570
 Circa 1981-82
 Made in Japan

"WORLD AC POWER"

for sale
 Pioneer DT-570 Audio Timer. These were originally designed for setting your system to record scheduled FM radio shows and Album rock. They also can be used to turn your system into a Super-Hi-Fi Alarm clock radio and / or just as the ultimate and really cool digital clock.
This is from a collection of these that took us a long time to amass. Many of these will erratically change / advance the time after they've been on for 1 or 2 hours. This is one of the few out of the many we get that keeps time perfectly and was checked over a 1 week period. Entire unit was disassembled and cleaned inside and out, including the internal switches.  All functions test perfectly. This is the one with the Aqua Blue Fluorescent digital readout and black face plate. Use it to turn on most anything with a latched or mechanical power switch. Will switch up to 1200 watts via dual AC outlets. Unit looks near new and works great! Clock memory is volatile at power outages. Measures 16.5" wide x 5.5" deep and 2" high and weighs 4 lbs unpacked. Includes our standard 90 day limited warranty.

 PIONEER
 DT-510
 Cond. 8.5
 $129.


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)











-

TAPE NOISE REDUCTION UNITS





MISC PROCESSORS

DBX-3BX-II_Series-2_3-Band_Stereo_Dynamic_Range_Expander_Perspective_web.jpg (27543 bytes)   DBX-3BX-II_Series-2_3-Band_Stereo_Dynamic_Range_Expander_collage.jpg (125477 bytes)

NEW LISTING 1/7/15
 (Click on above thumbnails to enlarge photos. SORRY for the highly compressed photos, as they're from one of our previous cameras)
VINTAGE DBX 3BX-II / SERIES TWO
DBX 3-BAND DYNAMIC RANGE EXPANDER
CIRCA 1970'S
for sale
THE famous and VERY sought after, Expander / Enhancer! Just about every audiophile system has or should have one of these included in the signal chain! They really brighten up you sound and recordings making them come Alive! It covers all three bands of the audio spectrum, Lows - Mids – Highs, set at 200 Hz and 4 kHz filter points. The expander can be positioned Pre or Post in the audio signal chain. Expansion is infinitely variable from 0-50% and the transition level can be varied by any amount 0-100. The Gain change readout ranges from -20db to +12db. This thing has a variable Dynamic Range of 101-115dBv! Frequency response range of 20Hz-20,000Hz. The series II also features a very important feature that the series I doesn't. A Bypass switch. Maximum input / output voltage of 6 volts so it can even work in a professional sound system. Is also rack mountable with optional rack ears (not included). Unit looks GREAT (essentially NEW) and sounds great! Linear slide controls have non-original knobs by Pioneer installed.  Measures standard rack width of 17" wide x 1.75" (1 rack space) high x 9.5" deep and weighs only 5 lbs unpacked. With original box and packing, and comes with a copy of the original DBX 3BX-TWO owners / users / operations manual. Includes our standard 90 day limited warranty!

DBX-3BX-II
Cond. 9
$389.






           NEW LISTING 1/4/14
 (Click on above thumbnails to enlarge photos)
PRE-OWNED
RADIO SHACK / REALISTIC 42-2105
REALISTIC TAPE CONTROL CENTER
TRIPLE INPUT / OUTPUT TAPE MONITOR / TAPE INPUT SELECTOR
SIGNAL-PROCESSOR SELECTOR


for sale


ü  Our technician has completely gone through and 'Certified' this unit.

ü
Entire unit disassembled for refurb / bench check / testing / repair

ü  Most I/O jack and fader solder joints re-flowed for trouble-free service.

ü  All toggle switches cleaned (entire circuit board must be removed to access).

ü  All 'latched' switches locking fine.

ü  We then tested both channels with a teope, analyzing both channels with and without each independent effect loop.
ü  It was then cosmetically detailed inside and out.

ü   All functions tested for perfect operation.


ü   While the 'bats' (handles) on these switches are suscetible to breaking due to rough handling, all the switches on this particular unit intact and fine. (we have spare switches for these 'just in case'. Overall, still looks nice and works perfectly following restoration!
 ______________________________


Very versatile unit allows selection between up to 3 tape decks (Reel to Reels, Cassette Decks, 8-Track Decks, DAT's, CDR's, iPod's, MP3 Players, DVD Players,  Audio etc.) or up to 3 Audio Signal Processors (Reverbs, enhancers, delays, dynamic processors, EQ's etc.)

ü  Connects easily to the ‘Tape-In’ / ‘Tape-Out’ jacks on your existing Stereo Receiver, Pre-Amp or Integrated Amplifier. If you don’t have a ‘true’ tape-monitor or ‘tape-loop’ you can also connect it simply to an input. You just won’t have any ‘record’ capabilities.

ü  ‘Triple’ 'TRUE' tape monitors (Tape Monitors can be used with Tape decks such as Cassette Tape Recorders/ Players, Reel to Reel's, 8-Track Tape Cartridge Decks, Video / CD / DVD / VCR / DAT / MP3 / iPod® / iPad® / iPhone® / iTouch® / iGadget / MP3 / XM® / SIRUS® CDR (CD recorders as well as for inserting signal processors, such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc)

ü  ‘Bi-Directional’ Dubbing / Copying from one deck to another

ü  Can also be used to connect ‘Signal Processors’ such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc, instead of ‘Source / Record’ devices

ü  Inputs could be used for turntables with the addition of a simple ‘phono pre-amp’ available here…

ü  Completely ‘passive unit, meaning no ‘power’ or ‘power supply’ required for operation

ü  Toggle Switch routing eliminates the hassle of ‘swapping’ patch cables and cords.

ü  Easy to connect and use!

All functions test great. These are great "tools" to have in any audio rack. Greatly enhances the versatility of most audio systems. The unit works and looks great. Comes with an 'e' copy / pdf download of the Realistic Tape Control Center / 42-2105 owners / users / operations manual. Measures 6.25" wide x 4.75 deep x 2.25" tall. Includes our standard 90 day limited warranty!
REALISTIC 42-2105 TAPE SWITCHER / SELECTOR
Cond 8.5++

$49.


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)






NEW LISTING 1/7/15
 (Click on above thumbnails to enlarge photos. SORRY for the highly compressed photos, as they're from one of our previous cameras)
PRE-OWNED
DBX TAPE NOISE REDUCTION UNIT
NX-40 NX40
DBX TYPE II
#...5837
Circa 1982-86

for sale
Great for use with Reel to Reel decks or Cassette Decks. Blows Dolby B or C out of the water! DBX has been used in recording studios for years. Gets rid of tape hiss. Period! Will connect to any quality component system & / or analog studio deck. Will also accept signals from those rare DBX encoded LP's. Record and Playback levels located on rear panel. Utilizes dual 'AN6291' dbx IC chips. This unit is in great condition. We have completely gone through and tested the unit. Looks fine, sounds and works great! Unit is narrow at 7" wide x 9" deep x 1.75" (1 rack space) tall and weighs ~3 lbs unpacked. Comes with a copy of the dbx NX-40 owners / users manual. Includes our standard 90 day limited warranty.
DBX NX-40
Cond. 8.5
$99.


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)









-


FOR MORE "SOLD / ARCHIVED" UNITS PAGE - CLICK HERE!



RECENTLY SOLD UNITS BELOW






        NEW LISTING 4/26/16
(Click on above thumbnails to enlarge photos)
VINTAGE
JVC GRAPHIC EQUALIZER
JVC SEA-10 / SEA10 EQ
STEREO, 1.66 OCTAVE, 5 / 7-BAND
#...
2186
Circa 1977
MIJ

SOLD 7/5/16
SHIPPED TO MARYLAND

Our technician has completely gone through and 'Certified' this unit.
Unit was disassembled for restoration / reconditioning. All toggle switches painstakingly cleaned. Linear faders still clean and retain their 'smooth' feel. Original LED 'power' indicator functioning fine. We then tested both channels with a test tone and O-scope, analyzing both channels with and without each independent effect. It was then cleaned inside and out, then polished to look great. Floor noise measured to -60dB! Only issue cosmetically is a minor scuff on the top edge and a minor cigarette burn to the top vinyl (neither particularly distracting).
 Unit performs and sounds great!
 ______________________________

Great design, build quality with no-excuse sonic quality and very easy to use. The JVC SEA-10, 5 / Pseudo-7-band "combined" stereo, graphic EQ. Combining the faders into stereo units, as opposed to separate left and right is so much easier to utilize for most users. One of the best built EQ's we had the pleasure to work on internally.

JVC SEA-10 features include:


- 1.66 Octave Graphic EQ
- 5-Physical faders / bands with the lowest and highest having selectable 'centers' Band, (combined stereo faders)
- +- 12dB Cut / Boost (most do only 10 dB)
- 5 frequency centers are as follows (starting at the low-end):
 Lowest band selectable 40Hz or 60Hz - 250Hz - 1kHz - 5kHz & the last / upper band is selectable 10kHz or 15kHz.
- LONG 70mm Linear faders utilizing super quality potentiometers
- 'True' Tape Monitor having both standard RCA and DIN (Tape Monitors can be used with Tape / Video / CD / DVD / VCR / DAT / MP3 / iPod® / iPhone® / iTouch® / iGadget / MP3 / XM® / SIRUS® CDR (CD recorders as well as for inserting signal processors, such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc) Dubbing can be used with CDR (CD recorders) units)
- SEA EQ 'Record' function, for imprinting EQ curve to recordings
- EQ defeat / bypass
- -6dB input attenuator on rear panel
- 'Un-switched' AC convenience jack rated for 150 Watts

JVC SEA-10 Original Specs:

# Channels: 2 (stereo)
# Bands: 5 w/ selectable extremes
# Cut / Boost dB's: 12±
Gain: 0dB
Recommended Input Level (RMS V): 0.5-0.8V
Output (RMS V): 1V
THD: <0.1% @ rated output, 20-20kHz
S/N A-weighted: 70 dB

This is a great looking and performing EQ and is built using super quality, de-tented linear controls  with a full 70mm of throw! Again, we have completely gone through cleaning it, refurbishing & checking all functions. All controls and switches cleaned for worry-free service. VERY well built, super clean (check out the THD rating), virtually NO crosstalk and sounds fabulous. Measures 7.5" wide x 10" deep x 5.25" high and weighs 6 lbs unpacked.
 Comes with an 'e' copy / pdf download of the JVC SEA-10 owners / users / operations manual. Includes our standard 90 day limited warranty.
JVC SEA-10 GRAPHIC EQUALIZER
Cond. 8.5

SOLD 7/5/16
SHIPPED TO MARYLAND

(Above text property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)





       NEW LISTING 4/26/16
(Click on above thumbnails to enlarge photos)
PRE-OWNED
REALISTIC EQ
DUAL 12 BAND STEREO EQ
REALISTIC 31-2009
#...434
Circa 1982-83

SOLD 8/29/16
SHIPPING TO KENTUCKY

Our technician has completely gone through and 'Certified' this unit.
Unit was disassembled for restoration / reconditioning.
Classy looking silver face, Realistic 24 band Equalizer (12 bands per stereo channel). Dual Tape Monitors with bi-directional dubbing. Output level control. Built in Dynamic Range Expander by 'IMX'. This is actually one of the best sounding EQ's we have had come through the site! Very "musical" sounding with lots of clarity and punch, but then check out the S/N ratio in the specs!

Realistic 31-2009
features:



- Dual 12 band, 'Octave' Graphic EQ

- Each of the graphic controls feature a full +-12db of cut / boost (instead of the common 10 db)
- 30mm in throw length, high quality, linear, de-tented faders
- 12 frequency centers are as follows starting at the low-end: 30Hz - 63Hz - 110Hz - 190Hz - 330Hz - 580kHz - 1kHz - 1.7kHz - 3kHz - 5.2kHz - 9kHz & 16kHz.
- Dual Tape Monitor
(Tape Monitors can be used with Tape / Video / CD / DVD / VCR / DAT / MP3 / iPod® / iPhone® / iTouch® / iGadget / MP3 / XM® / SIRUS® CDR (CD recorders as well as for inserting signal processors, such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc) Dubbing can be used with CDR (CD recorders) units)
- Bi-Directional Dubbing
- 'IMX' licensed 'Dynamic Range Expander' w/ infinitely variable 'depth' control
- EQ Recording function to imprint tapes / CD's / DAT's / Hard Drive with EQ curve for playback on a car stereo or to allow for deficiencies in speakers.
- Dual infinitely variable 'Output Level' controls
- EQ bypass
- An un-switched AC convenience jack located on the back rated at 200 Watts


Realistic 31-2009 original specs:

# Channels: 2 (stereo)
# Bands: 24 (12/channel)
# Cut / Boost dB's: 12±
Freq Response w/ EQ 'Zero'd': 5-50kHz +.05dB / -1dB
THD: 0.02% @ rated output, 20-20kHz
S/N A-weighted: 90 dB !!!


 Unit is clean both cosmetically and sonically. Looks fine and sounds great! Un-switched, 200 watt AC outlet on rear panel. We have completely gone through it, checking all functions. This is the third or forth one of these we had in the past 18 years, and they never hang around long. Includes our standard 90 day limited warranty.
REALISTIC 31-2009
 Condition 8.5+
SOLD 8/29/16
SHIPPING TO KENTUCKY


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)











NEW LISTING 5/3/16
(Click on above thumbnails to enlarge photos)
PIONEER SG-9500 / SG9500
VINTAGE PIONEER GRAPHIC EQUALIZER
Circa 1977-79

"WORLD AC POWER" ™
MIJ

SOLD 5/13/16
SHIPPING TO NORTH CAROLINA

ü  Our technician has completely gone through and 'Certified' this unit.

ü
  Everything was completely tested and benched.

ü  Most I/O jack and fader solder joints re-flowed for trouble-free service.

ü  Tape monitor and 'EQ' switches cleaned

ü  We replaced the 'Power' indicator lamp

ü  We then tested both channels with a test tone and O-scope, analyzing both channels with and without each independent effect.

ü  It was then cosmetically detailed inside and out.

ü  All functions tested for perfect operation.

ü  All inputs tested and both side produces clean and even sine waves!

ü  Checked with oscilloscope. No power supply hum of any kind. <00.1mvAC! It's dead silent!


ü  Cosmetically in 'Near New' condition

 One of the two sought after Pioneer Graphic EQ's. The Pioneer SG-9500. Classic Vintage 70's Pioneer look. Face is a thick milled, brushed aluminum plate with matching milled, aluminum switch caps. These look great racked up in a "Spec" System, and of course will add great sonic control to most stereo systems. Super quality build inside and out.
  Pioneer SG-9500 Features include:


- One Octave Graphic EQ
  - 10 Graphic bands of control
  - +- 10dB Cut / Boost
  - 70mm Long Throw, Linear Pots
 - Individual OP amps per each frequency range, 'no caps' results in stable performance over time since caps can drift in values
  - The 10 frequency centers are as follows (starting at the low-end):
  32Hz-64Hz-125Hz-250Hz
  -500Hz-1KHz-2KHz-4KHz
  8KHz & 16KHz
  - Tape Monitor
 (Tape Monitors can be used with Video / CD / DVD / VCR / DAT / iPod / MP3 / XM / SIRUS CDR (CD recorders as well as for inserting signal processors, such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc) Dubbing can be used with CDR (CD recorders) units)
  - EQ Record function, for imprinting EQ curve to recordings
  - EQ defeat / bypass
 - Rear mounted, Un-switched AC convenient outlet rated at 200 watts


Pioneer SG-9500 Original Specs:


 # Channels; 2 (stereo)
 # Graphic Bands;
10
 # Cut / Boost dB's: 10±
 Input Impedance 100kΩ
 Output Impedance: 600 Ω
 Signal to Noise Ratio
 (IHF, A Network, short circuited, 2V Output)
90dB
 THD @ 20Hz - 20kHz, All Control Flat Output 1 V: 0.04%
 THD @ 1 kHz, All Control Max. Output 3V: 0.04%
 THD @ 1 kHz, All Control Flat Output 2V: 0.03%
 THD @ 1 kHz, All Control Min. Output 1V: 0.05%
 Frequency Response: 5Hz - 70kHz  +0,-1dB


 Each of the graphic controls are an extra-long 80mm in throw length (most home units are 30mm. Unit has been completely evaluated, tested and cleaned inside & out. Even though the power indicator lamp was in fine working order, we replaced it for future years of trouble-free service. We also disassembled, cleaned and re-lubed the "varnished" power switch shaft plunger. We also, of course cleaned both the Tape Monitor and EQ Bypass switch contacts for silent operation (they were actually already quiet). Works and sounds GREAT! Looks fabulous with only some very minor scuffs on the top edge of the face plate and the  sheet metal cover. Comes with an 'e-copy / pdf download' of the Pioneer SG-9500 owners / users / instruction manual. Measures 16.5" wide x 13" deep x 6" high and weighs 15 lbs unpacked. Includes our standard 90 day limited warranty.

 PIONEER SG-9500 GRAPHIC EQUALIZER
Cond. 8.5+

SOLD 5/13/16
SHIPPING TO NORTH CAROLINA

(C) R.R.


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)













         NEW LISTING 12/6/13

(Click on above thumbnails to enlarge photos)
VINTAGE PIONEER SG-60
GRAPHIC EQUALIZER EQ
#...789S
STEREO 12 BAND "OCTAVE" EQ
Circa 1984-85
"WORLD AC POWER" ™
MIJ

SOLD 2/14/16
SHIPPED TO TENNESSEE


ü  Our technician has completely gone through and 'Certified' this unit.

ü  AC voltage selector corrected for North American AC Power / Current.

ü
Everything was completely tested and benched.

ü  Most I/O jack and fader solder joints re-flowed for trouble-free service.

ü  Tape monitor and Attenuator switch locks checked for proper function. All 'latched' switches locking fine.

ü  We checked and replaced lamps where needed.

ü  We then tested both channels with a test tone and O-scope, analyzing both channels with and without each independent effect.

ü  It was then cosmetically detailed inside and out.

ü  All functions tested for perfect operation.

ü  All inputs tested and both side produces clean and even sine waves!

ü  Checked with oscilloscope. No power supply hum of any kind. It's dead silent!


ü  Only minor cosmetic issues in that there are a couple of 'dark' areas to the upper edge of the face plate (not visible from a 'head on' view) and some light scuffing to the case / cover (see photos above). Overall, still looks nice and sounds great!
 ______________________________

The Pioneer, SG-60 Dual 10-band stereo, graphic EQ.
Pioneer SG-60 features include:


- 'One Octave' Stereo, 12-band Graphic EQ
- 12 'linear-fader' controlled frequencies per channel
- +- 12dB Cut / Boost (most EQ's only allow 10dB)
- The 12 frequency centers are as follows (starting at the low-end): 16Hz - 32Hz - 64Hz - 125Hz - 250Hz - 500kHz - 1kHz - 2kHz - 4kHz - 8Hz - 16kHz & 32kHz.
- 60mm Linear faders utilizing high quality potentiometers with a 'center detent'
- Dual Tape monitors (Tape Monitors can be used with Tape / Video / CD / DVD / VCR / DAT / MP3 / iPod® / iPhone® / iTouch® / iGadget / MP3 / XM® / SIRUS® CDR (CD recorders as well as for inserting signal processors, such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc) Dubbing can be used with CDR (CD recorders) units)
- EQ Record function, for imprinting EQ curve to recordings

- EQ defeat / bypass
- Selectable 'Line Out' (we've never seen an EQ with this that we can remember)
- AC un-switched convenience jack located on the back, rated at a total of 100 Watts

- "WORLD AC POWER"™ 50 / 60 cycles there is a 110V, 120V, 220V & 240V selector for use anywhere in the world!


Pioneer SG-60 Original Specs:

# Channels: 2 (stereo)
# Bands: 20 (12 stereo)
# Cut / Boost dB's: 12±
THD: 0.001% @ 2V output & 1kHz
Gain: 0dB w/ all controls 'centered'
Output (RMS V): 6V @ 1K w/ 0.01% THD
Overall Frequency Response: 10-100kHz
Input Sensitivity / Impedance: 150mV / 47
Output Sensitivity / Impedance: 150mV / 200Ω
Tape Output Impedance: 150mV / 2.2kΩ
S/N A-weighted (IHFA): 120dB @ 2V output


Overall, this is a great looking and performing EQ and is built using quality, center de-tented linear controls with +/- 12dB of range and a full 60mm of throw! Other than the previously mentioned light scuffing to the top cover and the scuffs to the upper front edge (not visible from 'head-on'), the unit looks great. Again, we have completely gone through cleaning it, refurbishing & checking all functions. All controls and switches cleaned for worry-free service. Measures 16.5" wide x 14" deep x 5.25" high and weighs 12 lbs unpacked. Includes our standard 90 day limited warranty.
PIONEER SG-60 STEREO GRAPHIC EQ
Cond. 8.5

SOLD 2/14/16
SHIPPED TO TENNESSEE


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)








NEW LISTING 6/22/16
(Click on above thumbnails to enlarge photos)

PRE-APPRECIATED
YAMAHA GRAPHIC EQUALIZER
YAMAHA EQ-630
ELECTRONIC
STEREO GRAPHIC
ONE OCTAVE EQUALIZER
W/ SPECTRUM ANALYZER AND 8 CURVE PRESETS

#...B043

"WORLD AC POWER"™

MADE IN JAPAN

for sale
SOLD 8/3/16
SHIPPED TO CALIFORNIA


Great quality, Dual 10-band, Electronic EQ, with the convenience of preset / memory curves. This is a great performing / versatile graphic eq.

Yamaha EQ-630 features:



- Each of the graphic controls feature selectable +/-12db of cut / boost (most EQ's allow only 10dB Cut or Boost)
- Independent L & R EQ control
- Full Fluorescent display screen for system status
 - Vertical 13-Segment Spectrum Analyzer w/ divisions for each frequency center
- Peak Hold function on Spectrum Analyzer

- Reverse curve selector

- 8 EQ Curve presets (4 User and 4 Factory)

- 10 frequency centers are as follows: 30Hz - 60Hz - 120Hz - 240Hz - 480Hz - 1kHz - 2kHz - 4kHz - 8kHz & 16kHz
- Tape monitor / Input
(Tape Monitors can be used with Tape decks such as Cassette Tape Recorders/ Players, Reel to Reel's, 8-Track Tape Cartridge Decks, Video / CD / DVD / VCR / DAT / MP3 / iPod® / iPad® / iPhone® / iTouch® / iGadget / MP3 / XM® / SIRUS® CDR (CD recorders as well as for inserting signal processors, such as EQ's, Reverbs, Spatial Enhancers / Dynamic Processors, Noise Reduction units, Special Effects units, Time Delays, etc)
- "EQ Record" function allows EQ curve to be imprinted to tape / recording
- Toggles display from Graphic position indicators to Spectrum Analyzer display

- True "WORLD AC POWER"™  50 / 60 cycles and there is also a 110V, 120V, 220V & 240V selector for use anywhere in the world!

Yamaha EQ-630 Original Specs:

# Channels: 2 (stereo)
# Bands: 20 (10 / channel)
# Cut / Boost dB's: Selectable 12±
THD: 0.1% @ 1V output & 1kHz
Gain: 0dB w/ all controls 'centered'
Rated Output (RMS V): 1V @ 1K w/ 0.006% THD
Max Output (RMS V): 7V @ 1K w/ 0.1% THD
Rated Input (RMS V): 1V
Max Input (RMS V): 7V
Overall Frequency Response: 10-50kHz
Input Sensitivity / Impedance: 150mV / 47kΩ
Tape Level / Impedance: 150mV / 47kΩ
S/N A-weighted (IHFA): 105dB @ 1V output w EQ flat


EQ is in great shape and looks great. Only minor cosmetic issue is some 'circular' scuffing on the top panel (see photos above) We have completely gone through this unit and tested all functions. Unit works and sounds GREAT! While unit was originally controllable by a remote control, none is included. Measures 17.25" wide x 10.7" deep x 4" tall and weighs 8 lbs unpacked. Includes our standard 90 day limited warranty.
YAMAHA EQ-630
Cond. 8.5
(C) R.R.

SOLD 8/3/16
SHIPPED TO CALIFORNIA


(Above text, in it's entirety, property of www.oaktreevintage.com / Oak Tree Enterprises, LLC. See 'Copyright Information' page for details)







NEW LISTING 7/2/10
(Click on above thumbnails to enlarge photos)

PRE-OWNED

MONSTER
"POWERCENTER"
              HTS-2500 MKII
HTS2500 MK II

AC POWER CONDITIONER / SURGE PROTECTOR

for sale
We have just had our tech go through this unit. When it came in it had the Monster 'death beep' as most used one's do. He was able to

Click here for more info...










**
"(actual as measured)" refers to original test results done by Hirsch-Houck Laboratories upon test release of product when new. Current "aged" specifications / performance may of course vary from that.









LINKS TO OUR 'HI-FI' DEPARTMENTS

Amps and
Pre-Amps

Receivers

Cassette
Decks

Tuners

Turntables

8-Track Decks

CD Players

Reel-Reel
Decks

EQs and Signal
Processors

Speakers

Betamax and
VHS VCRs

Turntable Cartridges

Tube Audio

Ne'cessories

Speaker Parts

Record Players

Vintage Radios

Vintage
Walkmans

Headphones

Stereo Parts


Wondering where the "tone" you remember went?....

Vintage  Stereo Equipment receivers speakers Classic Silver Audio Collection and jerry gahagan



.... Surround yourself with Silver and find it again!



POLICIES, SPECIFICATIONS, AVAILABILITY, INFORMATION
AND PRICING SUBJECT TO CHANGE  AT ANYTIME  AND
WITHOUT PRIOR
NOTICE
and changes may not be posted to web immediately
.


20-30% restock fee / service charge applies to all returns for refund depending on item specifics & / or individual distributor / drop shipper policies.
See our "
Warranties / Returns" page via the link below for more details.

$20. Minimum Orders

Visa Credit Card Logo                 American Express Credit Card Logo                Mastercard Credit Card Logo              Discover Credit Card Logo

   *HOME PAGE*   |   CONTACT & ORDERING  PARTS CONTACT  |  FAQ'S  I   SELLING-TRADING-CONSIGNING    |   CONDITION RATINGS   |   ORDERING / POLICIES   |   WARRANTIES / RETURNS   |   SHIPPING    |   HOLD / SOLD   |  RESTORATION PROCEDURES  I  LINKS   |  CLIENT LIST  |

Copyright © 1997-2016 Oak Tree Enterprises, LLC
COPYRIGHT INFORMATION



Please be patient while page loads . . .
