NICORDER 750 TAPE / PHONOGRAPH
INFORMATION REFERENCE PAGE



This page is dedicated to one of the 'coolest', vintage reel to reel decks we have crossed paths with. A Nicorder model 750 Stereo Tape Recorder w/ built-in 4-Speed Phonograph, 'Transcription Tone Arm' and 8mm Film Synchronizer. It also features built-in Stereo-Tube Amplifier and matching Speakers. At this writing it also appears to have been associated with early Akai. Built by Nishikura Tape Recorder Co., LTD in Japan.








NICORDER 750 TAPE / PHONOGRAPH INFORMATION REFERENCE PAGE

THESE ARE PHOTO EXAMPLES OF CUTS WE MADE TO A FORMICA COUNTERTOP TO DETERMINE WHICH METHOD WOULD WORK FOR US TO FINISH OFF THE  'END' PRIOR TO INSTALLING THE FORMICA END-TRIM


(Unrelated photo to be replaced)

Construction started 5/19/19:

This page is dedicated to one of the 'coolest', vintage reel to reel decks we have crossed paths with. A Nicorder model 750 Stereo Tape Recorder w/ built-in 4-Speed Phonograph, 'Transcription Tone Arm' and 8mm Film Synchronizer. It also features built-in Stereo-Tube Amplifier and matching Speakers. At this writing it also appears to have been associated with early Akai. Built by Nishikura Tape Recorder Co., LTD in Japan. Circa...We are working on reconstructing the owners manual, brochure, specification sheet, and related paper work (they were damaged and the pages 'welded together' (appears to be with 'mouse pee'. yes we have to do some 'gross stuff' here). At some point we also hope to restore / refurbish / bring back to life the Nicorder model 750 reel to reel / phonographe / tube amplifier unit.
This appears to be from Circa 1961. This unit was likely purchased in Tokyo, Japan and brought over to America by a GI stationed there.

NICORDER 750 FEATURES:



- Stereo Record and Playback on 4-Tracks
- Monophonic record and Playback on 4-Tracks
- Stereo Phonograph with Simultaneous Recording Available
- Your voice may be recorded while taping from Phonograph
- Can be used as a public address system, with Simultaneous Recording Available
- Built-in Stereo Recording / Playback 2-Channel Pre-Amplifiers, plus 2-Channel 4 Watt Amplifiers (Tube)


NICORDER 750 SPECIFICATIONS:
UNDER CONSTRUCTION 5/19/19



Recording Track / Head / Head-stack Format: Inline (4-track / 4-channel, stereo / monaural system) AC Bias

Ferrite Erase and 'Permalloy' Record and Playback heads
Motors: 3X. Capstan motor: 4/8 pole, large size Hysteresis synchronous. Reel motors: 6-pole, eddy current

Reel Size: max
Tape Speeds: 3.75 ips or 7.5 ips (can be adjusted from ??ips Max to 2.75ips min by Variable Speed Regulator
Phonograph
Speeds: 78RPM, 45RPM & 33.3 RPM (16RPM???)
Tape Speed accuracy: 0.5%
Frequency Response:
40-16,000 Hz @ 7.5ips.

50-10,000 Hz @ 3.75ips.

Wow and Flutter: <3% @ 3.75ips & <2% @ 7.5ips
S/N ratio: >45dB
Crosstalk; >50dB down adjacent track
Record Level Indicator: Dual VU Meters
THD: <1% @ 0VU & @ 1kHz. 3% @ +9VU & @ 1kHz
VU Meters; approx; -25dB to +5dB VU range

Bias Frequency; 100kHz

Line Input: Impedance 'High'
Microphone
Input: 50kΩ
Record Level Calibration: 0 VU reference is 250 nWb/m (nano-Webers per meter) tape flux level; adjustable LEDís preset to turn On at signal level of +10 VU.
Line Output: -10dB (0.3V) nominal & -+18dB (8.0V) nominal /  Impedance 10kΩ unbalanced

Fast Wind Time: Approx 120 Seconds for 1200'
Tube Compliment: 2x "6AU6", 4x 12AX7, 2x "6AQ5", 1x 6AR5 & 1x "5RK16"
Start Time (stop to full motion play): .05 sec @ 15ips & .04 sec @ 7.5 ips

Output Power (Amplifier) 4W / Channel
AC Power Requirements: 50 & 60Hz,
??"V & 180 Volt Ampere Max
Dimensions &
Weight (Tape Deck): 20" W x ??"D x 9" H & 48 lbs
Dimensions & Weight (Speakers clipped together as a pair): 15" W x ??"D x 12.5" H & 19 lbs







(Unrelated photo to be replaced)




(Unrelated photo to be replaced)











The information contained here is simply my personal findings and is not intended for anyone / or any entity to use to make any decisions to repair, disassemble, modify, or do anything. It is strictly for entertainment value. Please do not email any responses or call with any information related to it. It is also likely to change as new / additional information comes to light, or I change my mind or opinion. So There!
