LUXMAN R-800M / R-800E / R800M / R-800S / R-800U etc. MULTIPLEX STEREO RECEIVER PARTS / SPARES.
for sale
Some parts
MAY also fit the Lux R-820 stereo receiver, but do your research as we have no definitive info.
This Luxman R-800M was parted out due to an issue with the tuning flywheel. A previous DIY person was trying to repair it, and by the time we got it, it was missing, along with other 'cosmetic' parts. We bench tested it anyway and it performed flawlessly. Strong, clean tuner on both AM and FM, all inputs functioned including both Phono inputs, and the amp produced a strong 51.7 Watts at 8 Ohms and 72.25 Watts at 4 Ohms. AC idle draw was .28 Amps. AC floor noise was measured at R=00.1mVAC and L=00.2mVAC. DC offset measured at L=5.9mV and R=1.4mV.

 - PARTING OUT -


Bonnet / Case / Cover / Cabinet, Wood veneer cabinet, minor nicks - $
SOLD

Panel, Front / Face panel / aluminum – SOLD

Panel, ‘Tuning Scale’, plastic - $25.

Knobs / Caps / Buttons, Volume knob - SOLD

Knobs / Caps / Buttons,  Function, Speaker, Treble, Bass, Tuning knob – SOLD

Knobs / Caps / Buttons, Flip / toggle switch caps ‘Source’, ‘Deck Monitor’, ‘High Cut’, ‘Low Cut’, ‘Reverse Mode’, ‘Loudness’, ‘FM mute’ (3 caps remaining) - $25. ea.

Knobs / Caps / Buttons. ‘Balance knob’ - SOLD

Meter, ‘Tuning Signal Strength’ Meter - $25.

Meter, ‘Tuning; Frequency Centering’ Meter - $25.

Socket, Stereo Indicator rubber lamp socket / holder - $18.

Dial Pointer, Tuning dial pointer / needle / indicator (illuminated w/ lamp) - $25.

LUXMAN R-800M / LUX R800M STEREO RECEIVER PARTS / SPARES

Potentiometer / Control
, ‘Volume / Balance’ control pot, 440-200k BX2 ALPS - $40.


Potentiometer / Control, ‘Treble Right’, ‘Treble Left’ Tone pot, Alps 44E-50kB - $35. ea.

Potentiometer / Control. ‘Bass Right’, ‘Bass Left’ Tone pot, Noble B100kA=S - $35. ea.

Potentiometer / Control.’ Microphone Level’, Alps 440-100kA on circuit board ‘#PB-844’ with cap / knob - $35.

Switches / Selectors, Rotary / Wafer ‘Speaker Selector’ switch- $40.

Switches / Selectors, Rotary / Wafer ‘Function’ switch / selector - $40. ea.

Switches / Selectors, ‘Power’ Push switch, E-42153/Schadow typ-NE-15 w/ black plastic cap / button - $35.

Switches / Selectors, ‘Tape Monitor / ‘Reprint’, ‘Deck Monitor’, Alps toggle switches - $35. ea.

Switches / Selectors, 'High Cut’, ‘Low Cut’, ‘Reverse Mode’ Alps Toggle switches - $35. ea.

Switches / Selectors
, 'Loudness’, ‘FM Mute’, Alps Toggle switches - $35.ea.

Capacitor, Tuning capacitor, 7-Gang Alps 1108-U FL516U14 7407- $55.

String Wheel, Plastic String Tuning Wheel- $35.

Panel, Tuning dial scale illuminator shield / lamp holder - $25. (bulbs / lamps not included)

LUXMAN R-800M / LUX R800M STEREO RECEIVER PARTS / SPARES

Circuit Board, ‘FM Tuning’ board #PB-351 w/ transistors; 2SC372, 2SC381, 2SC1000, NEC2S640, IC Chips; NEC Up5540 TA7061AP, LM7031K, LUX-14562 / 010474 and balance of resistors, capacitors and diodes - $65.

Circuit Board, ‘Output’ / ‘Amp Driver’ Circuit board #PB-840, with Transistors; 2SA733, NEC 2SB536, 2SC945, NEC 2SC1507, NEC 2SD381 , JRC 2SA620 and balance of capacitors, resistors, filter caps, (less heat sink and output transistors) - $65.

Circuit Board, ‘Pre-amp’ Phono / Microphone pre-amplifier circuit board #PB-843, with Transistors; 2SA631, NEC 2SA640, NEC 2SC1345 and balance of capacitors, Tantulam capacitors resistors - $45.

Circuit Board, ‘Protection’ board, #PB-846, transistors; 2SA561, 2SC495, 2SC734, 2SC1345, and balance of capacitors, resistors, filter caps (less relay) - $45.

Circuit Board, ‘AM Tuning’ board #PB458a, Transistors; 2SC372, 2SC381, and balance of capacitors, resistors, tuning transformers, micro pots, etc. - $45.

Circuit Board, Switch / Bass Tone Circuit Board, ‘PB-841, includes transistors; NEC 2SA640, 2SC1345, capacitors, Tantulam capacitors, and resistors
(less potentiometers & toggle switches) - $35.

Circuit Board, ‘Toggle’ Switch Circuit Board, ‘PB-842, includes transistors; NEC 2SA640, 2SC1345, capacitors and resistors (less toggle switches) - $35.

Relay, Protection Relay, Takamisawa Relay MQR-307 - $35.

LUXMAN R-800M / LUX R800M STEREO RECEIVER PARTS / SPARES

Transformer, Power supply Transformer P-1847– Adjustable 120v-240v power option - $85.

Voltage Selector, AC mains / line voltage selector 100V / 110V, 220V / 240V switch - $35.

Rectifier Circuit, Rectifier diodes / caps on mounting blocks - $35.

Capacitors, Power supply filter Caps Elna 4700
μF 50 volts - $22. ea.

Capacitors, OEM caps Elna 3300uF 25 volts - $20. ea.

Transistors, OEM TO-3 ‘Output’ transistors; Toshiba 2SC793,  Toshiba 2SC663 - $25. ea.

Heat Sink, Power amp heat sink (less transistors) - $25. ea.

LUXMAN R-800M / LUX R800M STEREO RECEIVER PARTS / SPARES

Connector
, Circuit board multi-pin connectors - $20. ea

Jack / Connector
, ‘Phones’ / Headphone jack - $25.

Jack / Connector, Tape ‘DIN’ connector - $25.

Jack / Connector, RCA Input / Output  connectors / jacks  ‘Phono’, ‘AUX’, ‘Tape in’, ‘Tape out’, one bank with capacitors - $35.

Jack / Connector
, Speaker connectors / terminals, 2 complete banks of 2 pairs - $35.

Jack / Connector
, Speaker connectors / terminals, on fiber board as pairs / banks - $35. ea bank of 4

Jack / Connector, ‘Antenna’ Connectors / post / terminals on fiber board as set of 4 - $25.

Jack / Connector, Ground connector / post - $18.

Jack / Connector, AC Convenience outlet / Socket, ‘AC Convenience’ sockets with capacitors - $18. ea.

LUXMAN R-800M / LUX R800M STEREO RECEIVER PARTS / SPARES

Antenna, AM ‘Stick’ / bar / rod antenna with swivel / hinge mount - $35.

Fuse, Internal fuse ‘Holders’ / clips
(orange wires attach to these) - $25.

Fuse, ‘Holder’
(cap sold separately) - $25.

Fuse, ‘Cap’ (holder sold separately) - $30.

Panel, Rear sheet metal panel (less any input / output jacks / components) - $25.

Panel
, Bottom sheet metal - $20.

Foot / Feet, - $20. set of 4


Call or Email for "SHOWN and NOT marked 'SOLD' " part you need.
